Orbit motor 200cc, SMS200A432YGP

Payment options
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
€196.70
Tax included
On Request
Orbit motor 200cc, SMS200A432YGP gopart B480SMS200E4BDSP SMS200E432D00 SMS200E432D00GP
ON REQUEST

31485

  • Brand
  • Reference
    SMS200A432YGP
  • Condition
    New
  • CODE
    B480SMS200E4BDSP SMS200E432D00 SMS200E432D00GP
  • EAN
    8719493052022
Security policy
100% Secure payments
Delivery policy
Insured worldwide delivery
Return policy
30 days easy return

Comments (0)

No customer reviews for the moment.
Part number
SMS200A432YGP
EAN8719493052022
Unit
Each
Long description
Orbital motor type SMS / gopart
Details
  • High axial, radial axle load and a high torque
  • Runs very quietly at low speeds
Application range
  • Can be used wherever a high torque and low speeds are required
  • Also suitable for continuous reversal of rotation
  • Can be used continuously in high pressure conditions
Properties
  • With leakage oil drain
  • Roller construction
  • Tapered roller bearing
  • From the large orbit motors series
  • Robust and compact construction
  • Excellent starting characteristics
Benefits
  • Good price/performance ratio
  • Minimal loss of power
Flange shape
Square
Flange code
SAE-A
Number of mounting holes
4
Shaft type
Straight parallel
Shaft diameter
32 mm
Displacement
200 cm³/rev
Max continuous torque
438 N·m
Max. continous working pressure
160 BAR
Max intermittend working pressure
200 BAR
Max pressure peak
225 BAR
Max. flow rate
75 l/min
Max rotation speed
375 r/min
Min rotation speed
6 r/min
Main port thread diameter
1/2 Inch
Main port thread type
G
Drain port thread diameter
1/4 Inch
Drain port thread type
G
Port position
Side
L1Rotor length
32 mm
Max. power
14 kW
L2Main port center to front flange distance
145 mm
LHousing length
188 mm
