| Part number | CA26255 | |
|---|---|---|
| EAN | ||
| Unit | Each | |
| Details | Joint covered with a sealing cap | |
| Properties | Right-hand thread (R) or left-hand thread (L) | |
| Benefits | Protects against dust, spray and vapours | |
| Material | Zinc | |
| Consists of | With safety clip | |
| Total length | 45 mm | |
| BDistance end top to ball center | 20 mm | |
| EBall diameter | 19 mm | |
| AThread diameter - end side | M14 | |
| GThread diameter - rod side | M14 | |
| Thread direction - end side | Right | |
| Thread direction - rod side | Right | |
| CThread length - end side | 28 mm | |
| Thread pitch- end side | 1.50 mm | |
| Thread pitch - rod side | 1.50 mm | |
| FSpanner size | 16.0 mm | |
| DWorking length | 45 mm |
