| Part number | FPM10 | |
|---|---|---|
| EAN | ||
| Unit | Metre | |
| Application range | Suitable for all commercial fuels, including biodiesel, rapeseed oil and alcohol based fuels | |
| Properties | Resistant to ozone, oil and light | |
| Hose inside diameter | 3/8 Inch | |
| Hose inside diameter | 9.3 mm | |
| Max working pressure | 6 BAR | |
| Material inside | Fluo rubber [FPM] | |
| Bend radius | 90 mm | |
| Weight | 0.204 kg/m | |
| Type | Oil transmission hose | |
| Hose outside diameter | 15.3 mm | |
| Wall thickness | 3 mm | |
| Burst pressure | 35 BAR | |
| Medium |
| |
| Max working temperature | 110 °C | |
| Min working temperature | -30 °C | |
| Material outside | Fluo rubber [FPM] | |
| Reinforcement type | Braid | |
| Reinforcement material | Poly-aramid | |
| Max length | 10 m | |
| Norm | SAE 30 R9 | |
| DIN standard | 73379 | |
| Additional info | *Please note that this item is either a dangerous good or a non-standard delivery size. This means a specialist carrier will be used and this item will take upto 48 hours to deliver. |
