| Part number | GEV6LLMK8 | |
|---|---|---|
| EAN | ||
| Unit | Each | |
| Pros | 2S cutting ring | |
| Product details |
| |
| Long description |
| |
| DIN standard |
| |
| Surface treatment |
| |
| Body height | 11 mm | |
| L2Connection 2, centre to end distance | 9 mm | |
| Connection 2, thread pitch | 1.00 mm | |
| Connection 2, thread diameter | M8 | |
| Connection 2, thread type | Metric | |
| Connection 2, type | Thread taper | |
| Connection 2, type - male/female | Male | |
| L1Connection no 1 center to end distance | 20.5 mm | |
| Connection no 1 diameter | 6 mm | |
| KConnection no 1 thread length | 8 mm | |
| Connection no 1 type - male/female | Male | |
| Connection no 1 type | Cutting ring | |
| S1Connection no 1 wrench size | 12.0 mm | |
| Max working pressure | 100 BAR | |
| Pipe diameter | 6 mm | |
| Series | 6LL | |
| Shape | Straight - 2 connection sides |
