| Part number | G716961661042N | |
|---|---|---|
| EAN | ||
| Unit | Each | |
| Connection no 1 type | Quick coupling | |
| Connection no 1 type - male/female | Male | |
| Connection no 1 thread diameter | M30 | |
| Connection no 1 thread type | Metric | |
| HEX1Connection no 1 hex size |
| |
| Connectable under pressure | No | |
| ISO standard |
| |
| Outside diameter | 1.89 Inch | |
| D1Outside diameter | 48 mm | |
| L1Total length | 5.69 Inch | |
| L1Total length | 144.5 mm | |
| Material | Steel | |
| Surface treatment | Chromium-plated | |
| Max working temperature | 125 °C | |
| Min. working temperature | -25 °C | |
| Quick connection locking type | Radial balls | |
| Quick connection working type | Push to connect | |
| Seal material | Nitrile rubber [NBR] | |
| Series | 22L | |
| Valve type | Poppet | |
| Weight | 993.2 g |
