| Part number | G716961610041N | |
|---|---|---|
| EAN | ||
| Unit | Each | |
| Connection no 1 type | Quick coupling | |
| Connection no 1 type - male/female | Male | |
| Connection no 1 diameter | 30 mm | |
| Connection no 1 thread type | Metric | |
| HEX1Connection no 1 hex size |
| |
| Connectable under pressure | No | |
| ISO standard |
| |
| Inside diameter | 18.7 mm | |
| Outside diameter | 1.89 Inch | |
| D1Outside diameter | 48 mm | |
| L1Total length | 5.3 Inch | |
| L1Total length | 134.5 mm | |
| Material | Steel | |
| Surface treatment | Chromium-plated | |
| Max working temperature | 125 °C | |
| Min. working temperature | -25 °C | |
| Quick connection locking type | Radial balls | |
| Quick connection working type | Push to connect | |
| Seal material | Nitrile rubber [NBR] | |
| Valve type | Poppet | |
| Weight | 939.3 g |
