| Part number | GV5LL | |
|---|---|---|
| EAN | 8719607062725 | |
| Unit | Each | |
| Pros | Optimal cutting ring connection and functionality | |
| Product details |
| |
| Includes |
| |
| DIN standard |
| |
| Surface treatment |
| |
| Cone angle | 24 ° | |
| Connection 2, thread pitch | 1.00 mm | |
| Connection 2, thread diameter | M10 | |
| Connection 2, thread type | Metric | |
| Connection 2, type | Cone | |
| Connection 2, type - male/female | Female | |
| S2Connection 2, wrench size | 12.0 mm | |
| Connection no 1 diameter | 5 mm | |
| Connection no 1 thread pitch | 1.00 mm | |
| Connection no 1 thread diameter | M10 | |
| Connection no 1 thread type | Metric | |
| Connection no 1 type - male/female | Female | |
| Connection no 1 type | Cutting ring | |
| S1Connection no 1 wrench size | 11.0 mm | |
| L1Connections distance | 9 mm | |
| Max working pressure | 100 BAR | |
| Pipe diameter | 5 mm | |
| Series | LL | |
| Shape | Straight - 2 connection sides | |
| LTotal length | 35 mm |
