| Part number | GIR12DOINA | |
|---|---|---|
| EAN | 4012802526691 | |
| Unit | Each | |
| Diameter D4 | 17.5 mm | |
| Distance basis center shaft | 50 mm | |
| Edge degrees | 11 ° | |
| Height house | 8 mm | |
| Height inner ring | 10 mm | |
| Inner diameter | 12.00 mm | |
| Inside diameter | 12 mm | |
| Length L5 | 6.5 mm | |
| Length L7 | 18 mm | |
| Length | 67 mm | |
| Basic load ratings dyn. C | 10800 N | |
| Basic load ratings Stat. Co | 30400 N | |
| Suitable for original number | GIR12-DO | |
| Outside diameter basis | 19 mm | |
| Outside diameter bearing | 22 mm | |
| Outside diameter innerring | 14.9 mm | |
| Outside diameter | 34.00 mm | |
| Suitable for original number | GIR12-DO | |
| Thread | M12 | |
| Surface treatment | Zinc-plated | |
| Thread direction | Right | |
| Thread length | 23 mm | |
| Thread | M12 mm | |
| Thread type | Right Hand | |
| Type | Female thread | |
| Weight | 0.099 kg | |
| Width | 34 mm |
