| Part number | GAR35DO2RSINA | |
|---|---|---|
| EAN | 4012802525274 | |
| Unit | Each | |
| Technical info |
| |
| dHole diameter | 35 mm | |
| Hole length | 25 mm | |
| Bearing outside diameter | 55 mm | |
| Outside diameter of inner ring | 39.7 mm | |
| Edge angle | 6 ° | |
| d2Total length | 181 mm | |
| Shaft to center distance | 43 mm | |
| Thread diameter | M36 | |
| Thread pitch | 3.00 mm | |
| Thread direction | Right | |
| Thread length | 82 mm | |
| Hole centre to bottom distance | 140 mm | |
| Head outside diameter | 82 mm | |
| Head width (hole length) | 21 mm | |
| Surface treatment | Zinc-plated | |
| Basic radial load dynamic | 79900 N | |
| Basic radial load static | 159000 N | |
| Original number equivalent | GAR35-DO-2RS | |
| Weight | 1.4 kg |
