| Part number | GAR20DO2RSINA | |
|---|---|---|
| EAN | 4012802524987 | |
| Unit | Each | |
| Technical info |
| |
| dHole diameter | 20 mm | |
| BHole length | 16 mm | |
| DBearing outside diameter | 35 mm | |
| d1Outside diameter of inner ring | 24.1 mm | |
| Edge angle | 9 ° | |
| Total length | 104.5 mm | |
| Shaft to center distance | 27.5 mm | |
| d3Thread diameter | M20 | |
| Thread pitch | 1.50 mm | |
| Thread direction | Right | |
| L1Thread length | 43 mm | |
| hHole centre to bottom distance | 78 mm | |
| Head outside diameter | 53 mm | |
| C1Head width (hole length) | 13 mm | |
| Surface treatment | Zinc-plated | |
| Basic radial load dynamic | 29600 N | |
| Basic radial load static | 75600 N | |
| Original number equivalent | GAR20-DO-2RS | |
| Weight | 0.3 kg |
