Housing unit TME TME55 INA/FAG
search
  • Housing unit TME TME55 INA/FAG

Housing unit TME TME55

Payment options
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
€191.46
Tax included
4-5 Working days
Housing unit TME TME55 INA/FAG
IN WAREHOUSE

65333

Part number
TME55
EAN4012802823103
Unit
Each
Long description
Ball bearing units INA/FAG, series TME
Details
Triple seal on two sides
Application range
  • Mobile mechanical engineering
  • Stationary mechanical engineering
Properties
  • Inner bearing has extended inner ring with clamp ring on both sides
  • Subsequent lubrication possible
Benefits
Very good protection against contamination
Housing type
Round flange
dBearing inside diameter
55 mm
Consists of
  • Bearing block
  • Clamp ring
Housing width
185 mm
Total height
43.6 mm
Total width
71.4 mm
THousing height
27.5 mm
LBearing inner ring width
71.4 mm
CFlange thickness
15 mm
Locking ring outside diameter
76 mm
KMounting holes diameter
18 mm
Grease nipple thread diameter
M6
ZFitting edge diameter
125 mm
Weight
3.55 kg
Bearing material
Steel
Basic radial load static
29000 N
Basic radial load dynamic
43500 N
Original number equivalent
TME55
  • Brand
    INA/FAG
  • Reference
    TME55
  • In stock
    1 Item
  • Condition
    New
  • EAN
    4012802823103
