Housing unit UCF UCF205 INA/FAG 924110205
search
  • Housing unit UCF UCF205 INA/FAG 924110205

Housing unit UCF UCF205 924110205

Payment options
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
€21.83
Tax included
4-5 Working days
Housing unit UCF UCF205 INA/FAG 924110205
IN WAREHOUSE

65398

Part number
UCF205
EAN4047643228305
Unit
Each
Long description
These square ball bearing units with four bolt holes are pre-assembled and pre-lubricated. This makes them rapidly deployable. The self-aligning spherical outer ring of the wide inner ring ball bearing compensates for shaft misalignment.
Pros
  • Highly suitable for limited installation spaces
  • Assembled, ready for use
  • Pre-lubricated
Product details
  • Inner bearing has extended inner ring on both sides with 2 adjusting screws
  • Regreasable
  • Self-aligning ball bearing
  • Wide inner ring ball bearing
Properties
  • Inner bearing has extended inner ring with 2 adjusting screws on both sides
  • Can be subsequently lubricated
Includes
  • Bearing block
  • Bearing
  • Grease nipple
Housing type
Square flange
dBearing inside diameter
25 mm
aTotal length
95 mm
aHousing width
95 mm
Total height
35.7 mm
lHousing height
27 mm
BiBearing inner ring width
34 mm
Bearing balls distance to locking side end
16 mm
lBearing balls distance to mounting surface
14.3 mm
eMounting holes distance
70 mm
Mounting holes diameter
12 mm
Grease nipple thread diameter
M6
Basic radial load static
7800 N
Basic radial load dynamic
14000 N
Original number equivalent
UCF205-J7
  • Brand
    INA/FAG
  • Reference
    UCF205
  • In stock
    5 Items
  • Condition
    New
  • CODE
    924110205
  • EAN
    4047643228305
