Friction clutch K90TF W2400 561013890 Walterscheid 561020890
search
  • Friction clutch K90TF W2400 561013890 Walterscheid 561020890

Friction clutch K90TF W2400 561013890 561020890

Payment options
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
€645.37
Tax included
On Request
Friction clutch K90TF W2400 561013890 Walterscheid 561020890
ON REQUEST

66717

Part number
561013890
EAN
Unit
Each
Long description
Friction plate clutches with plate springs K90TF/K90/4TF
Pros
  • No power interruption
  • Catches peak loads for short periods of time
  • Maintains torque
  • Smooth running
Product details
  • Independent rotation direction
  • Power transmission via skid plates
  • Adjustable
  • Suitable as starting torque
  • Mowers
  • Power harrows
  • Pick-up
Clutch type code
K90
Connection locking type
Clamp bolt (interfering)
Outside connection diameter
  • 1-3/8 Inch
  • 1.375 Inch
Connection number of splines/grooves
6
Shaft size code
  • W2400
  • P400
Max. rotation speed
1000 r/min
Max static torque
900 N·m
Max dynamic torque
900 N·m
Cross cap diameter
32 mm
Cross length
86 mm
Outside diameter
190 mm
Clutch part length
45 mm
Original number equivalent
333298E
Suitable for machine/vehicle brand
IFA
  • CODE
    561020890
