EFK96/4R 1 3/4-6 TK138 210-II 5814451210 Walterscheid
search
  • EFK96/4R 1 3/4-6 TK138 210-II 5814451210 Walterscheid

EFK96/4R 1 3/4-6 TK138 210-II 5814451210

Payment options
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
€1,177.34
Tax included
On Request
EFK96/4R 1 3/4-6 TK138 210-II 5814451210 Walterscheid
ON REQUEST

66926

Part number
5814451210
EAN
Unit
Each
Details
  • Combination of freewheel and friction disc clutch
  • Absorbs peak loads for short periods
  • Protection for subsequent mass
  • Max. torque adjustable via circlip
Application range
  • Big balers
  • Round balers
  • Mowers
Properties
  • Depending on the direction of rotation
  • Power transmission via friction discs
  • No noise during friction
  • Noise when freewheeling
  • Suitable as a starting clutch
Technical info
Observe maintenance instructions
Benefits
  • Torque retention
  • Smooth transition
  • Easier coupling when PTO shaft is braked
  • Wide range of applications
Clutch type code
EFK96/4R
Connection locking type
Clamp cone
Outside connection diameter
  • 1-3/4 Inch
  • 1.75 Inch
Connection number of splines/grooves
6
Shaft size code
  • W2500
  • W2600
  • W2700
  • W2580
  • P580
Max. rotation speed
1000 r/min
Max static torque
2100 N·m
DOutside diameter
170 mm
Original number equivalent
1102854
Suitable for machine/vehicle brand
Eggers
