| Part number | 80220019 | |
|---|---|---|
| EAN | ||
| Unit | Each | |
| End cone length | 24 mm | |
| Head width | 63 mm | |
| Max. connection diameter | 20 mm | |
| Min. connection diameter | 18 mm | |
| Thread pitch- end side | 1.50 mm | |
| Thread pitch - rod side | 2.00 mm | |
| Thread diameter - end side | M16 | |
| Thread diameter - rod side | M24 | |
| Thread direction - rod side | Right | |
| Thread length - end side | 24 mm | |
| Thread type - end side | Metric | |
| Thread type - rod side | Metric | |
| Total length | 134 mm | |
| Working length | 135 mm |
