PTO shaft W400E L: 1010mm with overrunning clutch, W400E1010F51L Walterscheid 1694583
search
  • PTO shaft W400E L: 1010mm with overrunning clutch, W400E1010F51L Walterscheid 1694583

PTO shaft W400E L: 1010mm with overrunning clutch, W400E1010F51L 1694583

Payment options
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
€546.38
Tax included
4-5 Working days
PTO shaft W400E L: 1010mm with overrunning clutch, W400E1010F51L Walterscheid 1694583
IN WAREHOUSE

69932

Part number
W400E1010F51L
EAN
Unit
Each
Connection outside diameter by tractor side
1-3/8 Inch
Connection number of splines/grooves by tractor side
6
Locking type by tractor side
Collar lock
Attachment tractor side
Quick disconnect yoke
Connection outside diameter by machine side
1-3/8 Inch
Connection number of splines/grooves by machine side
6
Locking type by machine side
Collar lock
Attachment machine side
Overrunning clutch
Size code
W400E
Length
1010 mm
Power 540 rpm
28 kW
Power 1000 rpm
44 kW
Cross joint bush diameter by tractor side
32 mm
Cross joint length by tractor side
76 mm
Cross joint bush diameter by machine side
32 mm
Cross joint length by machine side
76 mm
Clutch type
F5/1L
Outer tube profile
2a
Outer tube wall thickness
4 mm
Outer tube large outside diameter
57.5 mm
Inner tube profile
1b
Inner tube wall thickness
4.5 mm
Inner tube large outside diameter
49 mm
Profile tube shape
Lemon
Max static torque
3400 N·m
Protection type
SD25
Original number equivalent
1610157
  • Brand
    Walterscheid
  • Reference
    W400E1010F51L
  • In stock
    1 Item
  • Condition
    New
  • CODE
    1694583
