  • Tow ball coupler 310 mm K80 03631041A02 Scharmüller 03631041

Tow ball coupler 310 mm K80 03631041A02 03631041

Payment options
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
€1,239.46
Tax included
On Request
Tow ball coupler 310 mm K80 03631041A02 Scharmüller 03631041
ON REQUEST

78281

Part number
03631041A02
EAN
Unit
Each
Application range
  • Couplers of the following ABGs can be coupled:
  • M9679, M9680, M9614, M9615, M9622, M9625, M9785, M9711, M9712 and with tow ball couplers to ISO 24347.
Properties
Optional retrofit with forced steering (right, left, both sides)
Benefits
  • Optimum driving comfort thanks to minimum clearance between vehicle and trailer
  • High support load
  • Larger axial and vertical swivel angle than with Piton-Fix and bolt couplings
  • Low wear and long service life
Track width
310 mm
Track thickness
38 mm
Locking pin diameter
25 mm
Adapter plate height
160 mm
Max. permissible D-Value
83.9 kN
Max. permissible vertical load
2000 kg
Colour
Black
Type
K80® Manual
Thread diameter
M20
Min. mounting holes distance
80 mm
Max. mounting holes distance
140 mm
Working length
150 mm
Extra info
Height Adjustable with Grabhandle
  • CODE
    03631041
