Hydraulic hose EN857-2SC-DN40 HSKPQ40

Name: Hydraulic hose EN857-2SC-DN40 HSKPQ40
Brand: Alfagomma
SKU: HSKPQ40
Price: 56.2 EUR
Availability: InStock

Payment options

€56.20

Tax included

4-5 Working days

Hydraulic hose EN857-2SC-DN40 HSKPQ40 Alfagomma

IN WAREHOUSE

ID: 88694

Description

Part number	HSKPQ40
EAN
Unit	Metre
Qty. Rounding	0.01
Pros	High operating pressure Small bending radius Extremely wear-resistant outer coating (15x vs standard) Outer coating resistant to ozone and oil
Product details	Hydraulic hose rubber compact with 2 braided steel wire layers of high tensile strength Essentially in line with DIN 20022- 2SN / EN857-2SC dimensions HSK-PQ 32 through HSK-PQ 50 must be peeled before use Available by the metre Available on 50-metre reel, up to 1/2" Available on 25-metre reel, up to 3/4" Always consult the latest press dimensions tables, see downloads at the bottom of each web page For longer single-piece lengths, please contact our sales department
Hose inside diameter	1-1/2 Inch
Hose inside diameter	38.1 mm
Max working pressure	125 BAR
Material inside	Synthetic rubber
Bend radius	430 mm
Weight	1.97 kg/m
Type	Hydraulic high pressure hose
DN	40 mm
Hose outside diameter	50.9 mm
Burst pressure	500 BAR
Medium	Hydraulic oil
Max working temperature	100 °C
Min working temperature	-40 °C
Material outside	Synthetic rubber
Reinforcement type	Braid
Reinforcement number of plies	2
Reinforcement material	Steel
Number of plies	2
EN standard	857 2SC
Approval	MSHA
