Platleņķa kardānvārpsta jūgvārpsta 20 L: 860mm, PTO20Y22TWS860GP gopart PTO20TWS860GP PTO20Y21TWS860GP
search
  • Platleņķa kardānvārpsta jūgvārpsta 20 L: 860mm, PTO20Y22TWS860GP gopart PTO20TWS860GP PTO20Y21TWS860GP

Platleņķa kardānvārpsta jūgvārpsta 20 L: 860mm, PTO20Y22TWS860GP

Apmaksas iespējas
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
268,69 €
AR PVN
4-5 Darba dienas
Platleņķa kardānvārpsta jūgvārpsta 20 L: 860mm, PTO20Y22TWS860GP gopart PTO20TWS860GP PTO20Y21TWS860GP
IR NOLIKTAVĀ

31181

Part number
PTO20Y22TWS860GP
EAN8719493114249
Unit
Each
Long description
Cost-effective alternative in the lower power range and suitable for log splitters, crop sprayers, fertiliser spreaders, manure spreaders etc.
Pros
Cost-effective alternative in lower power range
Product details
  • Max. dynamic capacity 540 rpm: 15kW
  • Max. dynamic capacity 1000 rpm: 23kW
  • The crossjoint side has a different build size
  • The right accessories can be found under spare parts and accessories
  • Meets all international safety requirements
  • Provided with "CE" marking
Application range
  • Slurry tanks
  • Crop sprayers
  • Fertiliser spreaders
  • Hay baler
Properties
  • Fulfils all international safety requirements
  • CE marking available
Technical info
  • Max. dynamic capacity at 540 rpm: 15 kW
  • Max. dynamic capacity at 1000 rpm: 23 kW
  • The cross coupling side varies in size
  • Matching accessories can be found under Spare parts and accessories
Benefits
Cost-effective alternative in lower power range
Connection outside diameter by tractor side
1-3/8 Inch
Connection number of splines/grooves by tractor side
6
Locking type by tractor side
Collar lock
Connection outside diameter by machine side
1-3/8 Inch
Connection number of splines/grooves by machine side
6
Locking type by machine side
Collar lock
Size code
PTO 20
Length
860 mm
Power 540 rpm
15 kW
Power 1000 rpm
23 kW
Cross joint bush diameter by tractor side - longer part
22 mm
Cross joint bush diameter by tractor side
23.8 mm
Cross joint length by tractor side - longer part
75.7 mm
Cross joint length by tractor side
61.4 mm
Cross joint bush diameter by machine side
23.8 mm
Cross joint length by machine side
61.4 mm
  • Zīmols
  • Norāde
    PTO20Y22TWS860GP
  • Pieejamās vispirms
    5 vienības:
  • Stāvoklis
    Jauns
  • Citi kodi
    PTO20TWS860GP PTO20Y21TWS860GP
  • EAN
    8719493114249
