• Orbit motors 40cc, SMP40A225YGP gopart B480SMP0362ADGP B480SMP0362ADSP SMP36A225YGP

Orbit motors 40cc, SMP40A225YGP

Apmaksas iespējas
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
161,96 €
AR PVN
Pēc pieprasījuma
Orbit motors 40cc, SMP40A225YGP gopart B480SMP0362ADGP B480SMP0362ADSP SMP36A225YGP
Uz pasūtījumu

31512

Part number
SMP40A225YGP
EAN8719607280334
Unit
Each
Long description
Orbital motor type SMP / gopart
Details
High axial, radial axle load and a high torque
Application range
  • Can be used wherever a high torque and low speeds are required
  • Can be used briefly in high pressure conditions
Properties
  • With leakage oil drain
  • Rotor construction
  • Wide shaft slip bearing
  • Can be connected to several motors in a row
  • Suitable for use in closed systems
  • From the medium-sized orbit motors series
  • Robust and compact construction
Benefits
Good price/performance ratio
Flange shape
Oval
Number of mounting holes
2
Shaft type
Cylindrical
Shaft diameter
25 mm
Displacement
40 cm³/rev
Max continuous torque
40 N·m
Max. continous working pressure
80 BAR
Max intermittend working pressure
120 BAR
Max pressure peak
180 BAR
Max. flow rate
40 l/min
Max rotation speed
980 r/min
Min rotation speed
30 r/min
Main port thread diameter
1/2 Inch
Main port thread type
BSP
Drain port thread diameter
1/4 Inch
Drain port thread type
BSP
Port position
Side
L1Rotor length
5.4 mm
Max. power
5.2 kW
  • Zīmols
  • Norāde
    SMP40A225YGP
  • Stāvoklis
    Jauns
  • Citi kodi
    B480SMP0362ADGP B480SMP0362ADSP SMP36A225YGP
  • EAN
    8719607280334
