Dubultā hidrauliskā šļūtene, DN10 CR1631010

Name: Dubultā hidrauliskā šļūtene, DN10 CR1631010
Brand: AGRALV
SKU: CR1631010
Price: 20.27 EUR
Availability: BackOrder

Apmaksas iespējas

20,27 €

AR PVN

Pēc pieprasījuma

Dubultā hidrauliskā šļūtene, DN10 CR1631010 AGRALV

Uz pasūtījumu

ID: 37950

Apraksts

Part number	CR1631010
EAN
Unit	Metre
Qty. Rounding	0.01
Details	Plastic hydraulic hose with 2 ply of high-strength Nylon wire mesh
Application range	Forklifts Lifting platforms Hose reels Mineral oil-based and glycol-based fluids Vegetable and mineral lubricants Crude oils, coolant
Properties	Very low bending radius Oil-resistant, smooth outer coating Thermoplastic hose
Technical info	Temperature for mineral oil based liquids: -50Â°C to +70Â°C Available lengths: by the metre
Benefits	Light, thin and flexible hose for relatively high operating pressure
Hose inside diameter	0.382 Inch
Hose inside diameter	9.7 mm
Max working pressure	250 BAR
Material inside	Polyester elastomer
Bend radius	55 mm
Weight	0.2 kg/m
DN	10 mm
Hose outside diameter	18 mm
Max working pressure	25
Burst pressure	1000 BAR
Max working temperature	70 Â°C
Min working temperature	-55 Â°C
Reinforcement type	Braid
Reinforcement material	Synthetic
