| Part number | G1294602 | |
|---|
| EAN | | |
|---|
| Unit | Each | |
|---|
| Details | - Low-frequency suspension
- Fully automatic active weight adjustment (50–130 kg)
- Optimum back support
- Ergonomically shaped cushions
- Active air-conditioning system, vents in the cushion
| |
|---|
| Application range | For large construction machines | |
|---|
| Properties | - APS: automatic positioning system
- Air-sprung seat
- With horizontal suspension, blocking
- Spring travel: 100 mm
- Height adjustment 80 mm, infinitely variable
- Horizontal adjustment 210 mm
- Backrest inclination adjustment
| |
|---|
| Benefits | - Comfortable
- User-friendly
- Relaxed driving
- Excellent lateral hold
- Good thermal management
| |
|---|
| Long description | - Application range:
- For large construction machines
- Benefits:
- Comfortable
- User-friendly
- Relaxed driving
- Excellent lateral hold
- Good thermal management
- Consists of:
- Seat contact switch
- Restraint system
- Inclination adjustable arm rests 80 mm x 380 mm
- Headrest
- Seat heating
- Store bag
- Details:
- Low-frequency suspension
- Fully automatic active weight adjustment (50–130 kg)
- Optimum back support
- Ergonomically shaped cushions
- Active air-conditioning system, vents in the cushion
- Properties:
- APS: automatic positioning system
- Air-sprung seat
- With horizontal suspension, blocking
- Spring travel: 100 mm
- Height adjustment 80 mm, infinitely variable
- Horizontal adjustment 210 mm
- Backrest inclination adjustme
| |
|---|
| Suspension type | Pneumatic | |
|---|
| Upholstery material | Fabric | |
|---|
| Upholstery colour | Black | |
|---|
| Total width | 490 mm | |
|---|
| Consists of | - Seat contact switch
- Restraint system
- Inclination adjustable arm rests 80 mm x 380 mm
- Headrest
- Seat heating
- Store bag
| |
|---|
| Armrests included | Yes | |
|---|
| Backrest extension included | Yes | |
|---|
| Seatbelt included | Yes | |
|---|
| Contact switch included | Yes | |
|---|
| Auto user weight adjustment | Yes | |
|---|
| Model | MSG95EL/722 | |
|---|
| Height adjustment | 8 cm | |
|---|
| Depth | 706 mm | |
|---|
| Min. working load | 50 kg | |
|---|
| Suspension stroke | 10 cm | |
|---|
| Max. working load | 130 kg | |
|---|
| Total height | 1089 mm | |
|---|
| Heating kit included | Yes | |
|---|
| Total length | 706 mm | |
|---|
| Supply voltage | 24 V | |
|---|
