| Part number | G1081366 | |
|---|
| EAN | | |
|---|
| Unit | Each | |
|---|
| Details | - Air-sprung seat
- Air-assisted weight adjustment
| |
|---|
| Application range | For small and narrow-track tractors, construction machines and mini excavators | |
|---|
| Properties | - Seat cushion width 450 mm
- Spring travel: 80 mm
- Height adjustment 60 mm, infinitely variable
- Horizontal adjustment 210 mm
- Weight adjustment 50–130 kg
- Weight 27 kg
- Lumbar support, mechanical
- Backrest inclination adjustment
| |
|---|
| Benefits | - Offers optimised seat comfort in the smallest of spaces
- A handle can be used to move the seat into the correct position
| |
|---|
| Long description | - Application range:
- For small and narrow-track tractors, construction machines and mini excavators
- Benefits:
- Offers optimised seat comfort in the smallest of spaces
- A handle can be used to move the seat into the correct position
- Consists of:
- Seat
- With compressor
- Without backrest extension
- Without arm rests
- Details:
- Air-sprung seat
- Air-assisted weight adjustment
- Properties:
- Seat cushion width 450 mm
- Spring travel: 80 mm
- Height adjustment 60 mm, infinitely variable
- Horizontal adjustment 210 mm
- Weight adjustment 50–130 kg
- Weight 27 kg
- Lumbar support, mechanical
- Backrest inclination adjustme
| |
|---|
| Suspension type | Pneumatic | |
|---|
| Upholstery material | PVC | |
|---|
| Upholstery colour | Black | |
|---|
| Total width | 470 mm | |
|---|
| Consists of | - Seat
- With compressor
- Without backrest extension
- Without arm rests
| |
|---|
| Armrests included | No | |
|---|
| Backrest extension included | No | |
|---|
| Seatbelt included | No | |
|---|
| Contact switch included | No | |
|---|
| Auto user weight adjustment | No | |
|---|
| Model | MSG93/521 | |
|---|
| Height adjustment | 6 cm | |
|---|
| Depth | 572 mm | |
|---|
| Min. working load | 50 kg | |
|---|
| Suspension stroke | 8 cm | |
|---|
| Max. working load | 130 kg | |
|---|
| Suitable for machine/vehicle model | MSG 93 / 521 | |
|---|
| Total height | 700 mm | |
|---|
| Heating kit included | No | |
|---|
| Total length | 572 mm | |
|---|
| Supply voltage | 12 V | |
|---|
