| Part number | 3206B2RSRTVH | |
|---|---|---|
| EAN | 4012802474510 | |
| Unit | Each | |
| dInside diameter | 30 mm | |
| DOutside diameter | 60 mm | |
| BWidth | 23.8 mm | |
| Rows number | 2 | |
| Sealing | 2RS | |
| Inner ring shape | Cylindrical | |
| Bearing model type | Angular contact ball bearings | |
| Basic radial load static | 222000 N | |
| Basic radial load dynamic | 31000 N | |
| Ref rotation speed | 6300 r/min | |
| Radial internal clearance code | CN | |
| Contact angle | 30 ° | |
| Max working temperature | 100 °C | |
| Min working temperature | -20 °C | |
| Outside diameter of inner ring | 35.6 mm | |
| Inside diameter of outer ring | 56.4 mm | |
| Regreasable | No | |
| Surface treatment | n/a | |
| Original number equivalent | 3206-BD-XL-2HRS-TVH |
