| Part number | GIKR8PWAINA | |
|---|---|---|
| EAN | 4012802526219 | |
| Unit | Each | |
| Technical info | PW - maintenance free (steel/PTFE material) | |
| Connection diameter | 16 mm | |
| D4Diameter D4 | 12.5 mm | |
| h1Distance basis center shaft | 36 mm | |
| C1Height house | 9 mm | |
| BHeight inner ring | 12 mm | |
| Inner diameter | 8.00 mm | |
| dInside diameter | 8 mm | |
| L5Length L5 | 5 mm | |
| L7Length L7 | 13 mm | |
| l4Length | 48 mm | |
| Basic load ratings dyn. C | 12900 N | |
| Basic load ratings Stat. Co | 13100 N | |
| Suitable for original number | GIKR8-PW-A | |
| dKOutside diameter ball | 15.88 mm | |
| WOutside diameter basis | 14 mm | |
| DOutside diameter bearing | 19 mm | |
| d1Outside diameter innerring | 10.3 mm | |
| d5Outside diameter | 24.00 mm | |
| Suitable for original number | GIKR8-PW-A | |
| Thread | M8 | |
| Surface treatment | Zinc-plated | |
| Thread direction | Right | |
| l3Thread length | 16 mm | |
| d3Thread | M8 mm | |
| Thread type | Right Hand | |
| Type |
| |
| Weight | 50.207 g | |
| d2Width | 22 mm |
