| Part number | GIKSR8PSINA | |
|---|---|---|
| EAN | 4012802544701 | |
| Unit | Each | |
| Connection diameter | 16 mm | |
| d4Diameter D4 | 12.5 mm | |
| h1Distance basis center shaft | 36 mm | |
| ßEdge degrees | 13 ° | |
| C1Height house | 9 mm | |
| BHeight inner ring | 12 mm | |
| dInside diameter | 8 mm | |
| l5Length L5 | 5 mm | |
| l7Length L7 | 12 mm | |
| l4Length | 48.5 mm | |
| Basic load ratings dyn. C | 12900 N | |
| Basic load ratings Stat. Co | 5700 N | |
| Suitable for original number | GIKSR8-PS | |
| dKOutside diameter ball | 15.8 mm | |
| WOutside diameter basis | 14 mm | |
| DOutside diameter bearing | 19 mm | |
| d1Outside diameter innerring | 10.3 mm | |
| Suitable for original number | GIKSR8-PS | |
| d3Thread | M8 | |
| Surface treatment | Zinc-plated | |
| Thread direction | Right | |
| l3Thread length | 12 mm | |
| d3Thread | M8 mm | |
| Thread type | Right Hand | |
| Type | Female thread | |
| Weight | 47.59 g | |
| d2Width | 25 mm |
