| Part number | GIHRK25DOBINA | |
|---|---|---|
| EAN | 4012802523195 | |
| Unit | Each | |
| Details | Smallest size | |
| Application range |
| |
| Properties |
| |
| Benefits | Low space requirement | |
| Inner diameter | 25.0 mm | |
| Suitable for original number | GIHRK25-DO-B | |
| Thread | Right | |
| Thread | M16x1.5 | |
| Type | Female thread | |
| L7Length L7 | 25 mm | |
| DOutside diameter bearing | 42 mm | |
| BHeight inner ring | 20 mm | |
| Outside diameter | 56.0 mm | |
| D1Outside diameter innerring | 29.3 mm | |
| D2Width | 56 mm | |
| H1Distance basis center shaft | 50 mm | |
| L3Thread length | 17 mm | |
| L4Length | 78 mm | |
| C1Height house | 23 mm | |
| D4Height basis | 25 mm | |
| D5Width basis | 41 mm | |
| ßEdge degrees | 7 ° | |
| Inner ring width | 20 mm | |
| Basic load ratings dyn. C | 48300 N | |
| Basic load ratings Stat. Co | 65500 N | |
| Ø Bore (mm) | 25 mm | |
| Thread type | Right Hand | |
| Weight | 0.48 kg |
