Gultņa ieliktnis 80x140x30mm GYE80KRRB

Name: Gultņa ieliktnis 80x140x30mm GYE80KRRB
Brand: INA/FAG
SKU: GYE80KRRB
Price: 252.55 EUR
Availability: BackOrder

Apmaksas iespējas

252,55 €

AR PVN

Pēc pieprasījuma

Gultņa ieliktnis 80x140x30mm GYE80KRRB INA/FAG

Uz pasūtījumu

ID: 63983

Apraksts

Part number	GYE80KRRB
EAN	4012802823141
Unit	Each
Product details	Both sides: extended inner ring with adjusting screws Convex outer ring with lubricating holes R seal Polyamide housing
Inside diameter	80 mm
Outside diameter	140 mm
Outer ring width	30 mm
Inner ring width	82.6 mm
Outside diameter of inner ring	97 mm
Locking screw centre to end distance	12 mm
Basic radial load static	54000 N
Basic radial load dynamic	72000 N
Wrench/Spanner size	5.0 mm
Ball centre to grease hole distance	8.8 mm
Sealing width	38 mm
Ball centre to end distance	33.3 mm
Original number equivalent	GYE80-KRR-B
Weight	2.57 kg
