Kāpurķēžu veltnis KR40XPPA

Name: Kāpurķēžu veltnis KR40XPPA
Brand: INA/FAG
SKU: KR40XPPA
Price: 84.91 EUR
Availability: BackOrder

Apmaksas iespējas

84,91 €

AR PVN

Pēc pieprasījuma

Kāpurķēžu veltnis KR40XPPA INA/FAG

Uz pasūtījumu

ID: 64495

Apraksts

Part number	KR40XPPA
EAN	4012802427868
Unit	Each
Long description	Track rollers single and double-row INA/FAG, series KR .. PPX
Details	Sealed on both sides by axially moving three-level plastic seal Thick-walled outer ring
Application range	Packaging machines Transport systems Roll-up doors Roller tensioners
Properties	Solid shaft with guide bore With axial guidance via driving discs NMT add-on: equipped with a nut
Benefits	Reduces friction and lubricant use Can absorb high radial loads
Inside diameter	18 mm
DOutside diameter	40 mm
Sealing	2RS
Bearing model type	Track rollers
Basic radial load static	16000 N
Basic radial load dynamic	10900 N
Rows number	1
Outer ring width	20 mm
d1Shaft diameter	18 mm
B1Shaft length	36.5 mm
G1Mounting thread length	19 mm
Max working temperature	100 °C
Min working temperature	-30 °C
Regreasable	Yes
Original number equivalent	KR40-X-PP-A
BTotal length	58 mm
Mounting thread pitch	1.50 mm
