Kāpurķēžu rullīšu gultnis NUKR72A INA/FAG
search
  • Kāpurķēžu rullīšu gultnis NUKR72A INA/FAG

Kāpurķēžu rullīšu gultnis NUKR72A

Apmaksas iespējas
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
205,46 €
AR PVN
4-5 Darba dienas
Kāpurķēžu rullīšu gultnis NUKR72A INA/FAG
IR NOLIKTAVĀ

64697

  • Zīmols
    INA/FAG
  • Norāde
    NUKR72A
  • Pieejamās vispirms
    5 vienības:
  • Stāvoklis
    Jauns
  • EAN
    4012802418033
Apmaksa
100% Droši maksājumi
Piegāde
Ātri piegādes risinājumi
Preču atgriešana
30 dienu preces atgriešanas iespēja

Komentāri (0)

Šobrid vēl nav klientu atsauksmju.
Part number
NUKR72A
EAN4012802418033
Unit
Each
Long description
Track rollers single and double-row INA/FAG, series NUKR
Details
  • Labyrinth seal
  • Thick-walled outer ring
  • Track is slightly ball-shaped
Application range
  • Packaging machines
  • Transport systems
  • Roll-up doors
  • Roller tensioners
Properties
  • Solid shaft with guide bore
  • With axial guidance via driving discs
  • Roller bearing is fully rolling
  • NMT add-on: equipped with a nut
Benefits
  • Reduces friction and lubricant use
  • Can absorb high radial loads
  • No forces on edges with uneven standing
Inside diameter
24 mm
DOutside diameter
72 mm
CWidth
28 mm
Sealing
ZZ
Bearing model type
Track rollers
Basic radial load static
65000 N
Basic radial load dynamic
45500 N
Rows number
2
Outer ring width
28 mm
d1Shaft diameter
24 mm
B2Shaft length
49.5 mm
IGMounting thread length
25 mm
GMounting thread diameter
M24
Max working temperature
140 °C
Min working temperature
-30 °C
Regreasable
Yes
Weight
0.986 kg
Original number equivalent
NUKR72-A
BTotal length
80 mm
Mounting thread pitch
1.50 mm
