Korpuss PCJT PCJT15

Name: Korpuss PCJT PCJT15
Brand: INA/FAG
SKU: PCJT15
Price: 40.05 EUR
Availability: InStock

Apmaksas iespējas

40,05 €

AR PVN

4-5 Darba dienas

Korpuss PCJT PCJT15 INA/FAG

IR NOLIKTAVĀ

ID: 64872

Apraksts

Part number	PCJT15
EAN	4012802799477
Unit	Each
Properties	Inner bearing has one-sided extended inner ring with clamp ring Can be subsequently lubricated
Housing type	Oval flange
dBearing inside diameter	15 mm
Consists of	Bearing block Clamp ring
Total length	57 mm
UHousing width	99 mm
UTotal height	39.1 mm
THousing height	25 mm
L*Bearing inner ring width	28.6 mm
Locking ring outside diameter	28 mm
Bearing balls distance to locking side end	17 mm
MMounting holes distance	76.5 mm
KMounting holes diameter	11.5 mm
Grease nipple thread diameter	M6
Weight	0.37 kg
Basic radial load static	4750 N
Basic radial load dynamic	10100 N
Original number equivalent	PCJT15
