Kvadrātveida atloka gultnis pilnīgs RCJY55

Name: Kvadrātveida atloka gultnis pilnīgs RCJY55
Brand: INA/FAG
SKU: RCJY55
Price: 109.28 EUR
Availability: InStock

Apmaksas iespējas

109,28 €

AR PVN

4-5 Darba dienas

Kvadrātveida atloka gultnis pilnīgs RCJY55 INA/FAG

IR NOLIKTAVĀ

ID: 65164

Apraksts

Part number	RCJY55
EAN	4064327016737
Unit	Each
Properties	Inner bearing has extended inner ring with 2 adjusting screws on both sides Can be subsequently lubricated
Housing type	Square flange
dBearing inside diameter	55 mm
ATotal length	162 mm
Housing width	162 mm
UTotal height	64.4 mm
Total width	55.6 mm
THousing height	43.5 mm
LBearing inner ring width	55.6 mm
Bearing balls distance to locking side end	31 mm
Mounting holes distance	130 mm
KMounting holes diameter	18 mm
Grease nipple thread diameter	M6
Weight	3.41 kg
Basic radial load static	29000 N
Basic radial load dynamic	46000 N
Original number equivalent	RCJY55
