Korpuss TCJ TCJ40N INA/FAG
IR NOLIKTAVĀ

65326

Part number
TCJ40N
EAN4012802799118
Unit
Each
Details
Triple seal on two sides
Application range
  • Mobile mechanical engineering
  • Stationary mechanical engineering
Properties
  • Inner bearing has extended inner ring with clamp ring on both sides
  • Subsequent lubrication possible
Benefits
Very good protection against contamination
Housing type
Square flange
Bearing inside diameter
40 mm
Consists of
  • Bearing block
  • Clamp ring
LTotal length
130 mm
Housing width
130 mm
Total height
59.1 mm
Flange thickness
12.5 mm
Mounting holes distance
101.5 mm
NMounting holes diameter
14 mm
Grease nipple thread diameter
M6
Weight
2.02 kg
Basic radial load static
19800 N
Basic radial load dynamic
34500 N
Original number equivalent
TCJ40-N
  • Zīmols
    INA/FAG
  • Norāde
    TCJ40N
  • Pieejamās vispirms
    5 vienības:
  • Stāvoklis
    Jauns
  • EAN
    4012802799118
