Dzīvojamā vienība TSHE TSHE20

Name: Dzīvojamā vienība TSHE TSHE20
Brand: INA/FAG
SKU: TSHE20
Price: 65.45 EUR
Availability: InStock

Apmaksas iespējas

65,45 €

AR PVN

4-5 Darba dienas

Dzīvojamā vienība TSHE TSHE20 INA/FAG

IR NOLIKTAVĀ

ID: 65345

Apraksts

Part number	TSHE20
EAN	4012802818932
Unit	Each
Details	Triple seal on two sides Short design
Properties	Inner bearing has extended inner ring with clamp ring on both sides Can be subsequently lubricated
Benefits	Very good protection against contamination Low space requirement
Housing type	Pillow block - short
Bearing inside diameter	20 mm
Consists of	• Bearing block Clamp ring
WTotal length	65 mm
BHousing width	32 mm
HTotal height	64 mm
LBearing inner ring width	43.7 mm
Flange thickness	12.5 mm
Locking ring outside diameter	33 mm
AShaft vertical distance	33.3 mm
OBearing balls distance to mounting surface	26.6 mm
Mounting holes distance	50.8 mm
Grease nipple thread diameter	M6
Mounting thread diameter	M8
Weight	0.49 kg
Original number equivalent	TSHE20-N
