Korpuss UCP UCP204

Name: Korpuss UCP UCP204
Brand: INA/FAG
SKU: UCP204
Price: 20.56 EUR
Availability: InStock

Apmaksas iespējas

20,56 €

AR PVN

4-5 Darba dienas

Korpuss UCP UCP204 INA/FAG

IR NOLIKTAVĀ

ID: 65386

Apraksts

Part number	UCP204
EAN	4047643247719
Unit	Each
Long description	These standing ball bearing units are pre-assembled and pre-lubricated. This makes them rapidly deployable. The self-aligning spherical outer ring of the wide inner ring ball bearing compensates for shaft misalignment.
Pros	Highly suitable for limited installation spaces Assembled, ready for use Pre-lubricated
Product details	Inner bearing has extended inner ring on both sides with 2 adjusting screws Regreasable Self-aligning ball bearing Wide inner ring ball bearing
Includes	Bearing block Bearing Grease nipple
Housing type	Pillow block
dBearing inside diameter	20 mm
aTotal length	127 mm
bHousing width	38 mm
WTotal height	64 mm
BiBearing inner ring width	31 mm
hShaft vertical distance	33.3 mm
nBearing balls distance to mounting surface	12.7 mm
eMounting holes distance	95 mm
Grease nipple thread diameter	M6
Original number equivalent	UCP204-J7
