Korpuss UCP UCP205

Name: Korpuss UCP UCP205
Brand: INA/FAG
SKU: UCP205
Price: 18.73 EUR
Availability: InStock

Apmaksas iespējas

18,73 €

AR PVN

4-5 Darba dienas

Korpuss UCP UCP205 INA/FAG

IR NOLIKTAVĀ

ID: 65430

Apraksts

Part number	UCP205
EAN	4047643247696
Unit	Each
Long description	These standing ball bearing units are pre-assembled and pre-lubricated. This makes them rapidly deployable. The self-aligning spherical outer ring of the wide inner ring ball bearing compensates for shaft misalignment.
Pros	Highly suitable for limited installation spaces Assembled, ready for use Pre-lubricated
Product details	Inner bearing has extended inner ring on both sides with 2 adjusting screws Regreasable Self-aligning ball bearing Wide inner ring ball bearing
Includes	Bearing block Bearing Grease nipple
Housing type	Pillow block
dBearing inside diameter	25 mm
aTotal length	140 mm
bHousing width	38 mm
WTotal height	71 mm
BiBearing inner ring width	34 mm
hShaft vertical distance	36.5 mm
nBearing balls distance to mounting surface	14.3 mm
eMounting holes distance	105 mm
Grease nipple thread diameter	M6
Original number equivalent	UCP205-J7
