Korpuss UCP UCP216 UCP216NB

Name: Korpuss UCP UCP216 UCP216NB
Brand: INA/FAG
SKU: UCP216
Price: 182.26 EUR
Availability: InStock

Apmaksas iespējas

182,26 €

AR PVN

4-5 Darba dienas

Korpuss UCP UCP216 INA/FAG UCP216NB

IR NOLIKTAVĀ

ID: 65439

Apraksts

Part number	UCP216
EAN	4054366895554
Unit	Each
Long description	These standing ball bearing units are pre-assembled and pre-lubricated. This makes them rapidly deployable. The self-aligning spherical outer ring of the wide inner ring ball bearing compensates for shaft misalignment.
Pros	Highly suitable for limited installation spaces Assembled, ready for use Pre-lubricated
Product details	Inner bearing has extended inner ring on both sides with 2 adjusting screws Regreasable Self-aligning ball bearing Wide inner ring ball bearing
Includes	Bearing block Bearing Grease nipple
Housing type	Pillow block
dBearing inside diameter	80 mm
aTotal length	292 mm
bHousing width	78 mm
WTotal height	174 mm
BiBearing inner ring width	82.6 mm
hShaft vertical distance	88.9 mm
nBearing balls distance to mounting surface	33.3 mm
eMounting holes distance	232 mm
Grease nipple thread diameter	M6
