Berzes sajūgs K90TF W2400 561013890 561020890

Name: Berzes sajūgs K90TF W2400 561013890 561020890
Brand: Walterscheid
SKU: 561013890
Price: 640.66 EUR
Availability: BackOrder

Apmaksas iespējas

640,66 €

AR PVN

Pēc pieprasījuma

Berzes sajūgs K90TF W2400 561013890 Walterscheid 561020890

Uz pasūtījumu

ID: 66717

Apraksts

Part number	561013890
EAN
Unit	Each
Long description	Friction plate clutches with plate springs K90TF/K90/4TF
Pros	No power interruption Catches peak loads for short periods of time Maintains torque Smooth running
Product details	Independent rotation direction Power transmission via skid plates Adjustable Suitable as starting torque Mowers Power harrows Pick-up
Clutch type code	K90
Connection locking type	Clamp bolt (interfering)
Outside connection diameter	1-3/8 Inch 1.375 Inch
Connection number of splines/grooves	6
Shaft size code	W2400 P400
Max. rotation speed	1000 r/min
Max static torque	900 N·m
Max dynamic torque	900 N·m
Cross cap diameter	32 mm
Cross length	86 mm
Outside diameter	190 mm
Clutch part length	45 mm
Original number equivalent	333298E
Suitable for machine/vehicle brand	IFA
