Berzes sajūgs W2500 K96/4 180daNm 5613651180

Name: Berzes sajūgs W2500 K96/4 180daNm 5613651180
Brand: Walterscheid
SKU: 5613651180
Price: 1047.46 EUR
Availability: InStock

Apmaksas iespējas

1 047,46 €

AR PVN

4-5 Darba dienas

Berzes sajūgs W2500 K96/4 180daNm 5613651180 Walterscheid

IR NOLIKTAVĀ

ID: 66749

Apraksts

Part number	5613651180
EAN	8432970131392
Unit	Each
Long description	Friction clutches with spring pack K96 / 4 cpl. 2400, 2500
Details	No interruption of power transmission Absorb peak loads for a short time Max. torque adjustable via circlip
Application range	Mowers Rotary harrows Pick-up
Properties	Independent of direction of rotation Power transmission via friction discs Adjustable Suitable as a starting clutch
Technical info	Observe maintenance instructions
Benefits	Torque retention Smooth transition Wide range of applications
Clutch type code	K96/4
Connection locking type	Clamp cone
Outside connection diameter	1-3/8 Inch 1.375 Inch
Connection number of splines/grooves	6
Shaft size code	W2500
Max. rotation speed	1000 r/min
Max static torque	1800 N·m
Cross cap diameter	36 mm
Cross length	100 mm
DOutside diameter	170 mm
LClutch part length	90 mm
Original number equivalent	1101735
Suitable for machine/vehicle brand	Rau
