Berzes sajūgs W2300-FK96R 105 daNm 5810750105

Name: Berzes sajūgs W2300-FK96R 105 daNm 5810750105
Brand: Walterscheid
SKU: 5810750105
Price: 1224.44 EUR
Availability: InStock

Apmaksas iespējas

1 224,44 €

AR PVN

4-5 Darba dienas

Berzes sajūgs W2300-FK96R 105 daNm 5810750105 Walterscheid

IR NOLIKTAVĀ

ID: 66886

Apraksts

Part number	5810750105
EAN	8432970155855
Unit	Each
Long description	Friction and overrunning clutches with spring pack FK96 cpl. 2300, 2400
Details	Combination of freewheel and friction disc clutch Absorbs peak loads for short periods Protection for subsequent mass Max. torque adjustable via circlip
Application range	Big balers Round balers Mowers
Properties	Depending on the direction of rotation Power transmission via friction discs No noise during friction Noise when freewheeling Suitable as a starting clutch
Technical info	Observe maintenance instructions
Benefits	Torque retention Smooth transition Easier coupling when PTO shaft is braked Wide range of applications
Clutch type code	FK96R
Connection locking type	Collar lock
Outside connection diameter	1-3/8 Inch 1.375 Inch
Connection number of splines/grooves	6
Shaft size code	W2300
Max. rotation speed	1000 r/min
Max static torque	1050 N·m
Cross cap diameter	27 mm
Cross length	84 mm
DOutside diameter	170 mm
LClutch part length	75 mm
Original number equivalent	1172703
Suitable for machine/vehicle brand	Matsui
