Kardānvārpsta P600 L 1210mm ar šķērsskrūves sajūgu P6001210S156552 Walterscheid
search
  • Kardānvārpsta P600 L 1210mm ar šķērsskrūves sajūgu P6001210S156552 Walterscheid

Kardānvārpsta P600 L 1210mm ar šķērsskrūves sajūgu P6001210S156552

Apmaksas iespējas
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
2 443,70 €
AR PVN
4-5 Darba dienas
Kardānvārpsta P600 L 1210mm ar šķērsskrūves sajūgu P6001210S156552 Walterscheid
IR NOLIKTAVĀ

68596

  • Zīmols
    Walterscheid
  • Norāde
    P6001210S156552
  • Pieejamās vispirms
    2 vienības:
  • Stāvoklis
    Jauns
Apmaksa
100% Droši maksājumi
Piegāde
Ātri piegādes risinājumi
Preču atgriešana
30 dienu preces atgriešanas iespēja

Komentāri (0)

Šobrid vēl nav klientu atsauksmju.
Part number
P6001210S156552
EAN
Unit
Each
Details
  • Dispense duration: 100–250 hours
  • Profiled guard tube prevents turning.
  • Sealed profile tube prevents infiltration of dirt.
  • Quickly removable shielding
  • No safety chain on tractor side required
Application range
  • Heavy-duty soil cultivating machinery
  • Wood shredders
  • Stump grinders
Properties
  • Fulfilling the requirements laid out in EC 89/392 EEC
  • Compliant with EN12965 safety standard
  • CE marking available
Technical info
  • See Walterscheid instruction manual
  • Values at working angle 5° and service life 1000 hours
  • LZ = closed length in mm, from intersection to intersection
Benefits
  • Longer service life than standard pto shaft
  • Lower maintenance costs
  • Faster coupling
Connection outside diameter by tractor side
1-3/8 Inch
Connection number of splines/grooves by tractor side
6
Consists of
  • Pto shaft with guard tube
  • Declaration of conformity
  • Instruction manual
Locking type by tractor side
Collar lock
Connection outside diameter by machine side
1-3/4 Inch
Connection number of splines/grooves by machine side
6
Locking type by machine side
Clamp cone
Attachment machine side
Shear bolt clutch
Size code
P600
Length
1210 mm
Cross joint bush diameter by tractor side
42 mm
Cross joint length by tractor side
104 mm
Cross joint bush diameter by machine side
42 mm
Cross joint length by machine side
104 mm
Max. clutch torque
4800 N·m
Outer tube profile
S6
Inner tube profile
S5H
Max static torque
7800 N·m
Protection type
PG30
Original number equivalent
1156550
Extra info
  • Standard shear bolt protection value is max 4800 Nm with bolt quality 8.8 (DIN 931 - M12x70)
  • and max 3600 Nm with bolt quality 6.8
