Kardānvārpsta bez jūgiem W2100 L: 1210mm, W21001210OG Walterscheid 1113120

Kardānvārpsta bez jūgiem W2100 L: 1210mm, W21001210OG 1113120

Name: Kardānvārpsta bez jūgiem W2100 L: 1210mm, W21001210OG 1113120
Brand: Walterscheid
SKU: W21001210OG
Price: 404.62 EUR
Availability: InStock

Apmaksas iespējas

404,62 €

AR PVN

4-5 Darba dienas

Kardānvārpsta bez jūgiem W2100 L: 1210mm, W21001210OG Walterscheid 1113120

IR NOLIKTAVĀ

ID: 69931

Apraksts

Part number	W21001210OG
EAN
Unit	Each
Long description	Series W2300 without yokes
Application range	Mowers Harvesters Seeders
Properties	Lubrication frequency from 50 to 100 hours Fulfils EC 89/392 EEC requirements Complies with EN12965 safety standard CE marking available
Technical info	See Walterscheid instruction manual Max. dynamic capacity 540 rpm: 28 kW, 500 Nm Max. dynamic capacity 1,000 rpm: 44 kW, 415 Nm Values at working angle 5° and service life 1000 hours LZ = slid-in length in mm, from intersection to intersection
Consists of	Pto shaft with guard tube Declaration of conformity Instruction manual Delivery without yokes
Locking type by tractor side	Cross
Attachment tractor side	n/a
Locking type by machine side	Cross
Attachment machine side	n/a
Size code	W2100
Length	1210 mm
Power 540 rpm	12 kW
Power 1000 rpm	18 kW
Cross joint bush diameter by tractor side	22 mm
Cross joint length by tractor side	55 mm
Cross joint bush diameter by machine side	22 mm
Cross joint length by machine side	55 mm
Outer tube profile	Oa
Inner tube profile	OOcH
Profile tube shape	Lemon
Max static torque	600 N·m
Protection type	SD05
Original number equivalent	1113120
