| Part number | 07639032A02 | |
|---|---|---|
| EAN | ||
| Unit | Each | |
| Application range | For towing eyes according to DIN/ISO 9678/5692-1 | |
| Properties | ABG no: M9668, M9720, e4 D0196 (ISO 6489-4) | |
| Track width | 390 mm | |
| Track thickness | 32 mm | |
| Locking pin diameter | 25 mm | |
| Adapter plate height | 160 mm | |
| Pull pin diameter | 44.5 mm | |
| Max. permissible D-Value | 89.3 kN | |
| Max. permissible vertical load | 3000 kg | |
| Colour | Black | |
| Thread diameter | M20 | |
| Working length | 166 mm | |
| Manufacturer | Scharmüller |
