K80 sakabes ieliktņi 05633055A02

Name: K80 sakabes ieliktņi 05633055A02
Brand: Scharmüller
SKU: 05633055A02
Price: 932.1 EUR
Availability: InStock

Apmaksas iespējas

932,10 €

AR PVN

4-5 Darba dienas

K80 sakabes ieliktņi 05633055A02 Scharmüller

IR NOLIKTAVĀ

ID: 78451

Apraksts

Part number	05633055A02
EAN
Unit	Each
Application range	Couplers of the following ABGs can be coupled: M9679, M9680, M9614, M9615, M9622, M9625, M9785, M9711, M9712 and with tow ball couplers to ISO 24347.
Properties	Optional retrofit with forced steering (right, left, both sides)
Benefits	Optimum driving comfort thanks to minimum clearance between vehicle and trailer High support load Larger axial and vertical swivel angle than with Piton-Fix and bolt couplings Low wear and long service life
Track width	330 mm
Track thickness	32 mm
Locking pin diameter	25 mm
Adapter plate height	150 mm
Max. permissible D-Value	82.2 kN
Max. permissible vertical load	3000 kg
Colour	Black
Type	K80® Manual
Working length	75 mm
Extra info	Height can be adjusted with a handle
