• Šļūtene 4K-DN32 280 bāri ABTE ABTEV4KDN324S Alfagomma ABTE4KDN324S

Šļūtene 4K-DN32 280 bāri ABTE ABTEV4KDN324S ABTE4KDN324S

Apmaksas iespējas
swedbank-icon.png citadele-icon.png visa-icon.png mastercard-icon.png paypal.png
48,90 €
AR PVN
Pēc pieprasījuma
Šļūtene 4K-DN32 280 bāri ABTE ABTEV4KDN324S Alfagomma ABTE4KDN324S
Uz pasūtījumu

86492

Part number
ABTEV4KDN324S
EAN
Unit
Metre
Long description
The updated Alfabiotech 4K 280 bar Evolution is stronger and more flexible than before. With its extremely small bending radius, which exceeds the standard by up to 60%, it can be used practically anywhere. Limited installation space and high performance go hand in hand. The wear-resistant outer shell also ensures a longer service life and thus reduced maintenance and replacement costs.
Show more
Pros
  • Resistant to biological oil
  • Highly durable outer shell
  • Extremely flexible
  • Very low bending radius
  • Robust hose with shear protection
Product details
  • Alfabiotech 4000
  • Standard: ISO 18752
  • MSHA approved
  • Temperature: -40°C to +121°C
  • For systems with very high peak and pulse pressures in e.g. agricultural and earth moving machinery and for use in drive shafts
  • Biological, mineral and glycol-based liquids
  • Robust interlock hose with shear protection
  • 4 steel inlays
  • Always consult the latest press dimensions tables, see downloads at the bottom of each web page
Hose inside diameter
1-1/4 Inch
Hose inside diameter
32 mm
Max working pressure
280 BAR
Bend radius
210 mm
Hose outside diameter
44.2 mm
Hose outside diameter
1.74 Inch
Size
32
Max working pressure
4000 lbf/in²
Burst pressure
1120 BAR
Burst pressure
112 MPa
Burst pressure
16000 lbf/in²
Max working temperature
120 °C
Max. working temperature
250 °F
Min working temperature
-40 °C
Min. working temperature
-40 °F
Number of plies
4
Bend radius
8.27 Inch
ISO standard
18752
  • Zīmols
  • Norāde
    ABTEV4KDN324S
  • Stāvoklis
    Jauns
  • Citi kodi
    ABTE4KDN324S
