Elkonis 9/16 JIC x 9/16 UNF KIU0909 K09SAE

Name: Elkonis 9/16 JIC x 9/16 UNF KIU0909 K09SAE
Brand: Alfagomma
SKU: KIU0909
Price: 10.41 EUR
Availability: BackOrder

Apmaksas iespējas

10,41 €

AR PVN

Pēc pieprasījuma

Elkonis 9/16 JIC x 9/16 UNF KIU0909 Alfagomma K09SAE

Uz pasūtījumu

ID: 88783

Apraksts

Part number	KIU0909
EAN
Unit	Each
Product details	UNF cone 37°
Long description	Details: adjustable coupling Technical information: For standpipes 37º (74º) against cone and inserts with UNF/JIC fittings acc. SAE I 514. Cone acc. To UNF ANSI.
Angle	90 °
Cone angle	74 °
Connection 2, centre to end distance	27 mm
Connection 2, thread diameter	9/16 Inch
Connection 2, thread type	UNF
Connection 2, threads per inch	18
Connection 2, type	Thread
Connection 2, type - male/female	Male
Connection no 1 center to end distance	31.5 mm
F1Connection no 1 thread diameter	9/16 Inch
Connection no 1 thread type	JIC
Connection no 1 threads per inch	18
Connection no 1 type - male/female	Male
Connection no 1 type	Thread
Material	Steel
Shape	Elbow - 2 connection sides
Surface treatment	Galvanised
Working pressure	380 BAR
