L veida tapa 9/16UNF x 1/4BSP LIB0904

Name: L veida tapa 9/16UNF x 1/4BSP LIB0904
Brand: Alfagomma
SKU: LIB0904
Price: 14.98 EUR
Availability: InStock

Apmaksas iespējas

14,98 €

AR PVN

4-5 Darba dienas

L veida tapa 9/16UNF x 1/4BSP LIB0904 Alfagomma

IR NOLIKTAVĀ

ID: 88830

Apraksts

Part number	LIB0904
EAN
Unit	Each
Product details	Position adjustable : BSPP cylindrical thread with o-ring and locking nut
Connection no 1 thread type	UNF
F1Connection no 1 thread diameter	9/16 Inch
Connection 2, thread type	BSP
F2Connection 2, thread diameter	1/4 Inch
Connection 2, centre to end distance	31.5 mm
Cone angle	74 °
Pipe diameter	3/8 Inch
D1Pipe diameter	10 mm
Material	Steel
Surface treatment	Galvanised
Working pressure	380 BAR
