Ievietojiet DN06-1/8 BSP PF62

Name: Ievietojiet DN06-1/8 BSP PF62
Brand: Alfagomma
SKU: PF62
Price: 2.63 EUR
Availability: InStock

Apmaksas iespējas

2,63 €

AR PVN

4-5 Darba dienas

Ievietojiet DN06-1/8 BSP PF62 Alfagomma

IR NOLIKTAVĀ

ID: 89416

Apraksts

Part number	PF62
EAN
Unit	Each
Product details	O-ring seal DKOR
Includes	Insert O-ring
Surface treatment	Zinc-plated White passivated
Cone angle	60 °
Connection 2, diameter	1/4 Inch
Connection 2, diameter	6 mm
Connection 2, type	Hose end
Connection 2, type - male/female	Male
CConnection centre to insert distance	14.2 mm
Connection no 1 thread diameter	1/8 Inch
Connection no 1 thread type	BSP
Connection no 1 type code	DKOR
Connection no 1 type - male/female	Female
Connection no 1 type	Cone
CH1Connection no 1 wrench size	14.0 mm
Height	19 mm 14 mm
ISO standard	228
Material	Steel
Shape	Straight - 2 connection sides
