Ievietot DN13-M22x1,5-15L-45° PGL132245 PGL132245DB

Name: Ievietot DN13-M22x1,5-15L-45° PGL132245 PGL132245DB
Brand: Alfagomma
SKU: PGL132245
Price: 5.19 EUR
Availability: InStock

Apmaksas iespējas

5,19 €

AR PVN

4-5 Darba dienas

Ievietot DN13-M22x1,5-15L-45° PGL132245 Alfagomma PGL132245DB

IR NOLIKTAVĀ

ID: 89418

Apraksts

Part number	PGL132245
EAN
Unit	Each
Product details	Cone, metal on metal seal Cutting ring adaptors L series 24° cone Adaptors with 60° cone Do not use for 4-layer hose ABT (4SP)
Long description	Application range: Cutting ring adapter series L, 24° cone Adapter with 60° cone Properties: Cone, metal on metal seal Technical information: Do not use for HDR hoses with 4 inserts (4SP)
Shape	Elbow - 2 connection sides
Connection no 1 type	Cone
Connection no 1 type - male/female	Female
Connection no 1 type code	DKM
Connection no 1 length	49 mm
Connection no 1 thread diameter	M22
Connection no 1 thread pitch	1.50 mm
HConnection no 1 wrench size	27.0 mm
LConnection no 1 center to end distance	80 mm
Connection 2, type	Hose end
Connection 2, type - male/female	Male
Connection 2, diameter	1/2 Inch
Connection 2, diameter	12 mm
DConnection 2, centre to end distance	22 mm
CConnection centre to insert distance	49 mm
Angle	45 °
Cone angle	60 °
Material	Steel
Surface treatment	Zinc-plated White passivated
Series	15L
