Vīriešu radze 7/8 JIC x M22 RIM1422WD

Name: Vīriešu radze 7/8 JIC x M22 RIM1422WD
Brand: Alfagomma
SKU: RIM1422WD
Price: 6.16 EUR
Availability: InStock

Apmaksas iespējas

6,16 €

AR PVN

4-5 Darba dienas

Vīriešu radze 7/8 JIC x M22 RIM1422WD Alfagomma

IR NOLIKTAVĀ

ID: 89780

Apraksts

Part number	RIM1422WD
EAN
Unit	Each
Product details	Screw-in side metric with WD seal For pipe with 37º (74º) flanged edge and hose with UNF / J.I.C. connection in accordance with SAE I 514. Connection thread on the 37° cone side is UNF in accordance with ANSI
Long description	Technical information: For standpipes 37º (74º) against cone and inserts with UNF/JIC fittings acc. SAE I 514. Cone acc. To UNF ANSI.
Cone angle	74 °
Connection 2, length	14 mm
F2Connection 2, thread pitch	1.50 mm
Connection 2, thread diameter	M22
Connection 2, thread type	Metric
Connection 2, type	Thread
F1Connection no 1 thread diameter	7/8 Inch
Connection no 1 thread type	JIC
Connection no 1 type	Thread
CHConnection no 1 wrench size	27.0 mm
Pipe diameter range	14-16 mm
Pipe diameter	5/8 Inch
Shape	Straight - 2 connection sides
Total length	43 mm
